| Application: |
- Brine, crude oil, mild chemicals, petroleum waste, sediments, sludge, slurries, water, Oil field waste recovery, general industrial
|
| Inner Tube: |
Black Nitrile/SBR |
| Reinforcement: |
Multiple textile plies with wire helix |
| Outer Cover: |
Black nitrile/SBR; corrugated wrapped finish |
| Temp. Range: |
-30°C to +85°C (-22°F to +185°F). |
| Hose I.D |
Hose O.D |
Working Pressure |
Minimum Bend Radius |
Approx. Weight |
| inch |
mm |
inch |
mm |
psi |
bar |
inch |
mm |
lbs/ft |
kg/m |
| 1-1/2 |
38.1 |
1.95 |
50.2 |
150 |
10.3 |
4.0 |
101.6 |
0.72 |
1.07 |
| 2 |
50.8 |
2.47 |
62.0 |
150 |
10.3 |
6.0 |
152.4 |
1.00 |
1.48 |
| 2-1/2 |
63.5 |
3.00 |
75.0 |
150 |
10.3 |
9.0 |
228.6 |
1.30 |
1.93 |
| 3 |
76.2 |
3.48 |
89.0 |
150 |
10.3 |
12.0 |
304.8 |
1.53 |
2.27 |
| 1-1/2 |
38.1 |
1.95 |
50.2 |
150 |
10.3 |
4.0 |
101.6 |
0.72 |
1.07 |
| 4 |
101.6 |
4.54 |
116.0 |
150 |
10.3 |
16.0 |
406.4 |
2.27 |
3.37 |
| 6 |
152.4 |
6.64 |
168.66 |
150 |
10.3 |
48.0 |
1219.2 |
4.19 |
6.23 |
|
